Microcosm hit-n-miss engine with custom oak cart
« on: April 08, 2019, 08:31:43 pm »
my weekend project, making a cart for the hit-n-miss engine.
the "rustic" look is intentional, the cast iron wheels came from Menards (less than $4.00 ea.) they are 2" cast iron casters , they have been trimmed down (narrower), cleaned up & had about 15 minutes lathe work on each, small holes drilled & beveled, hub cleaned up straight & true. all electronic components are hidden inside the oak frame, there is a plate that can be removed from underneath to access the batteries & spark box, I actually had planned on making a set of wheel chalks for it....but it doesn't really move much now with the additional weight. it rolls very well even though it doesn't need to...lol










Logged
Bruce, St. Paul Indiana, USA
"Originality thrives in seclusion free of outside influences beating upon us to cripple the creative mind."
  Nikola Tesla

SlowArrow

  • Jr. Member
  • **
  • Posts: 100
  • Location: SF Bay Area
Re: Microcosm hit-n-miss engine with custom oak cart
« Reply #1 on: April 08, 2019, 10:04:37 pm »
That’s pretty cool.  I’ve been thinking of building a skid out of oak to replace the box it comes with.  Be fun to see the other options people come up with.  Thanks for sharing yours!
Logged
Mike

IndianaRog

  • Global Moderator
  • Full Member
  • *****
  • Posts: 729
  • Location: Central Indiana
    • IndianaRog and the Temple of Steam
Re: Microcosm hit-n-miss engine with custom oak cart
« Reply #2 on: April 08, 2019, 10:10:08 pm »
Bruce, you have done it again.  I was looking forward to how you were going to pull this off.  I looked some online at cast iron wheels, but all seemed too big.  Your idea to turn them down on the lathe was great.  Cart looks real world right off the farm!

Sweet!

Rog
Logged
my YouTube channel:  https://www.youtube.com/results?search_query=indianarog

my website:  IndianaRog.com

Swift Fox

  • Full Member
  • ***
  • Posts: 546
  • Location: Leicestershire, UK
    • Swift Fox Steam Co
Re: Microcosm hit-n-miss engine with custom oak cart
« Reply #3 on: April 09, 2019, 03:57:48 am »
Bruce that looks fantastic!

I guess if you wanted to modify it further you could add a larger fuel tank and an exhaust pipe.

Logged
Your nose is before your eyes, so trust it first!

jkbixby

  • Sr. Member
  • ****
  • Posts: 1003
  • Location: Gahanna, Ohio
Re: Microcosm hit-n-miss engine with custom oak cart
« Reply #4 on: April 09, 2019, 06:56:40 am »
That's a good looking cart Bruce - I like the cast iron wheels and rough oak as it really does make it look correct.
Logged
Regards,
Larry

classixs

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 2432
  • Location: Jutland
    • www.SteamUp.dk
Re: Microcosm hit-n-miss engine with custom oak cart
« Reply #5 on: April 09, 2019, 08:28:00 am »
Looks fantastic sitting on that cart, great job Bruce !!!
Logged
Cheers
Jan
WEBSITE: SteamUp YOUTUBE: SteamUp

Hero

  • Sr. Member
  • ****
  • Posts: 1008
  • Location: Ontario, Canada
Re: Microcosm hit-n-miss engine with custom oak cart
« Reply #6 on: April 09, 2019, 08:36:39 am »
Clever use of the casters. I've often thought of using one for a small flywheel, but I've never yet got around to building an engine that needs one.
Logged
Bob

Stoker

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 3718
  • Wherever you go ......... there you are!
  • Location: Eastern Sierra
Re: Microcosm hit-n-miss engine with custom oak cart
« Reply #7 on: April 09, 2019, 09:22:29 am »
Nice job Bruce ... it looks the part and provides a heavy base so the engine doesn't jump around like it originally did.
Logged
"Information is not knowledge, Knowledge is not wisdom, Wisdom is not truth, Truth is not beauty, Beauty is not love, Love is not music: Music is THE BEST...
Wisdom is the domain of the Wis (which is extinct). Beauty is a French phonetic corruption of a short cloth neck ornament currently in resurgence..."
F. Zappa ... by way of Mary, the girl from the bus.

RedRyder

  • Administrator
  • Hero Member
  • *****
  • Posts: 4356
  • Location: Connecticut - USA
Re: Microcosm hit-n-miss engine with custom oak cart
« Reply #8 on: April 09, 2019, 09:50:19 am »
Nice work, Bruce...!!!
Logged
